PPTP

Point-to-Point Tunneling Protocol or PPTP is the most commonly used security protocol by VPN providers to secure their connections between the user and the VPN server. Even though PPTP is not considered the most secure protocol compared to the other protocols used, it is still preferred by some users and in some online situations. In this tutorial we will show you how to manually setup a VPN’s PPTP connection on your Windows Vista operated device.



Setting Up PPTP on Windows Vista



1- Right click on the networks icon in the system tray, and select “Open Network and Sharing Center



2-  In the “Network and Sharing Center” and under “Change your networking settings”, click on “Set up a new connection or network

3- From the list labeled “Choose a connection option”, select “Connect to a workplace” and click on “Next



4- Click on “Use my internet connection (VPN)



5- If you are asked “Do you want to use a connection that you already have”, select the radio button labeled “No, create a new connection” and click on “Next



6- In the field labeled “Internet address”, type in the IP address or the hostname of the VPN server you want to connect to (you can find this in the VPN provider’s website but make sure that the server you choose supports the PPTP protocol)



7-  In the field labeled “Destination name”, enter the name you want to give to the connection (it is preferred to give it the same name as your VPN provider)



8- Click to check the checkbox labeled “Don’t connect now; just set it up so i can connect later



9- Make sure that all other checkboxes are unchecked



10- At the bottom of the window, click on “Next



11- In the field labeled “Username” enter your VPN account username



12- In the field labeled “Password” enter your VPN account password



13- Click to check the checkbox labeled “Remember this password



14- Click on “Create



15- Click on “Close



16- Back in the “Network and Sharing Center” click on “Manage network connections” from the panel on the left side of the window



17- Right click the icon of the connection you just created and select “Properties



18- From the top of the “Properties” window, click to open the tab labeled “Networking



19- Click to open the drop-down menu labeled “Type of VPN” and select “PPTP VPN” and click “Ok



20- Back in the “Network Connections” window, double click on the icon of the connection you just created



21- In the connection window, click to check the checkbox labeled “Save this username and password for the following users:” and then either select the radio button labeled “Me only” or the radio button labeled “Anyone who uses this computer



22- Click on “Connect



23- Once the connection is established a window will appear asking you to select the location of the connection, whether it is “Home”, “Work”, or “Public location”. It is always preferred to select “Public location” as it is the most secure



24- Click on “Close



Now you have successfully manually configured a Point-to-Point Tunneling Protocol or PPTP connection on your Windows Vista operating  system.
